Mil 7 2.21m X2.13m X30.5m Military Gabion Box Hesco Defensive Barriers Steel Wire Material 3 Years Warranty

Mil 7 2.21m X2.13m X30.5m Military Gabion Box Hesco Defensive Barriers Steel Wire Material 3 Years Warranty

تصویر بزرگ :  Mil 7 2.21m X2.13m X30.5m Military Gabion Box Hesco Defensive Barriers Steel Wire Material 3 Years Warranty

جزئیات محصول:
محل منبع: چین
نام تجاری: KN
گواهی: ISO CE SGS COC
شماره مدل: جعبه گابیون نظامی
پرداخت:
مقدار حداقل تعداد سفارش: 50 واحد
قیمت: Negotiated
جزئیات بسته بندی: پالت و فیلم پلاستیکی در خارج
زمان تحویل: 15-20 روز کاری
شرایط پرداخت: Western Union، MoneyGram، L/C، T/T
قابلیت ارائه: 50 واحد در هفته
توضیحات محصول جزئیات
مواد: سیم فولادی سیم مش: 5.0 میلی متر
دیافراگم: 3 اینچ (76.2 میلی متر) x 3 اینچ (76.2 میلی متر) درمان سطح: گالوانیزه داغ داغ
ژئوتکستایل: 250-300 GSM رنگ شن و ماسه ، رنگ سبز طول عمر: 25 سال
اندازه: Mil 1 -mil 10 رنگ ژئوتکستایل: رنگ بژ-شنی
برجسته کردن:

Mil 7 Defensive Barriers,2.21m X2.13m X30.5m Military Defensive Barriers,Steel Wire Defensive Barriers

,

2.21m X2.13m X30.5m Military Defensive Barriers

,

Steel Wire Defensive Barriers

                    Military Gabion Box Hesco Defensive Barriers Steel Wire Material 3 Years Warranty



1. Introduction :

Hesco barriers (also known as “Hesco bastions”) share the same basic design but differ substantially between military and civilian applications. The key distinctions lie in design intent, operating environment, functional emphasis, and specification choices:


Military Gabion Box Defensive Barriers Steel Wire Material 3 Years Warranty is gabion box. It is a combination of welded wire mesh frame outside and non-woven geotextile liner inside. Sand, soil, gravel and blinding are frequently used as filling because of geotextile liner.


Gabion bastions are mainly used in military and flood control for its modular structure and quick setup. For military, a gabion with 24 inches thickness can stop rifle bullets, shell fragments and other shrapnel. While for flood protection, gabion can be assembled soonest and come into use.


Military Gabion Box Defensive Barriers Steel Wire Material 3 Years Warranty have been used in many countries around the world including Afghanistan, Iraq, Bosnia, Kosovo, Yemen, Sri Lanka, Jordan, UAE and Turkey. Most military organizations currently use this products including the US Army, UK MOD, USMC, USAF and NATO.


A galvanized steel unit lined with geotextile fabric,  Military Gabion Box Defensive Barriers Steel Wire Material 3 Years Warranty is completely assembled during manufacture, ensuring rapid installation. Available in a wide range of sizes, units can be joined and extended using the provided joining pins. The primary advantage of the product is its ability to utilise locally available fill material to rapidly construct walls and other structures with minimal manpower and resources.


2. Material:


It is made of galvanized welded mesh,spring with other fittings,can be filled with sand,earth,cement,stone,can be used in separate cell or some cells joint together.


3. Finish: electro galvanized,hot dipped galvanized,galfan coated,


4. Hesco  barrier Specifications:


1)  wire diameter: 4mm-5mm
2)  hole: 3''x3''
3)  size: 0.61x0.61m,1x1m,2.13x2.21m,other size can be produced as requested.
4)  geotextile: in non-woven geotextile,color can be white,beige-sand color.




                                         Hesco Defensive Barriers Specification



Model Height Width Length Internal Cells
KN-1(Mil 1) 54”(1.37m) 42”(1.06m) 32’9”(10m) 5+4=9 cells
KN-2(Mil 2) 24”(0.61m) 24”(0.61m) 4’(1.22m) 2 cells
KN-3(Mil 3) 39”(1.0m) 39”(1.0m) 32’9”(10m) 5+5=10 cells
KN-4(Mil 4) 39”(1.0m) 60”(1.52m) 32’9”(10m) 5+5=10 cells
KN-5(Mil 5) 24”(0.61m) 24”(0.61m) 10’(3.05m) 5 cells
KN-6(Mil  6) 66”(1.68m) 24”(0.61m) 10’(3.05m) 5 cells
KN-7(Mil 7) 87”(2.21m) 84”(2.13m) 91’(27.74m) 5+4+4=13 cells
KN-8(Mil 8) 54”(1.37m) 48”(1.22m) 32’9”(10m) 5+4=9 cells
KN-9(Mil 9) 39”(1.0m) 30”(0.76m) 30’(9.14m) 6+6=12 cells
KN-10(Mil 10) 87”(2.21m) 60”(1.52m) 100’(30.5m) 5+5+5+5=20 cells
KN-11(Mil  11) 48”(1.22m) 12”(0.30m) 4’(1.22m) 2 cells
KN-12(Mil  12) 84”(2.13m) 42”(1.06m) 108’(33m) 5+5+5+5+5+5=30 cells
KN-19(Mil  19) 108”(2.74m) 42”(1.06m) 10’5”(3.18m) 6 cells


 Defensive Barriers Use Deatils:



Unpack---Pull out and set up-----Connect together---- Fill and compact----Finished

Mil 7 2.21m X2.13m X30.5m Military Gabion Box Hesco Defensive Barriers Steel Wire Material 3 Years Warranty 0



Hesco Defensive Barriers Application :


 Perimeter security and defense walls
♦  Equipment revetments
♦  Personnel and material bunkers
♦  Observation points
♦  Defensive firing positions
♦  Guard posts
♦  Protection engineering of seaside area
♦  Border crossing checkpoints
♦  Protecting existing structures
♦  Flood control retaining wall



  • Military versions prioritise blast/ballistic protection and tactical adaptability for high-risk areas.
  • Civilian versions focus on rapid deployment, cost-effectiveness, and environmental compatibility for disaster response and everyday protection.


FAQ :



Q: Are you trading company or manufacturer ?
A: We are factory.


Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.


Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.


Q: What is your terms of payment ?
A: Payment<=1000 USD, 100% in advance. Payment>=1000 USD, 30% T/T in advance ,balance before shippment.


If you have another question, pls feel free to contact us .


Mil 7 2.21m X2.13m X30.5m Military Gabion Box Hesco Defensive Barriers Steel Wire Material 3 Years Warranty 1Mil 7 2.21m X2.13m X30.5m Military Gabion Box Hesco Defensive Barriers Steel Wire Material 3 Years Warranty 2
